540 MOD Functions
17.2 Software Numbers
17.2 Software Numbers
Application
The following software numbers are displayed on the TNC screen
after the MOD functions have been selected:
 NC: Number of the NC software (managed by HEIDENHAIN)
 PLC: Number and name of the PLC software (managed by your
machine tool builder)
 Feature Content Level (FCL): Development level of the software
installed on the control (see “Feature content level (upgrade
functions)” on page 10). The TNC displays --- on the
programming station, since there is no Feature Content Level
there.
 DSP1 to DSP3: Number of the speed controller software
(managed by HEIDENHAIN)
 ICTL1 and ICTL3: Number of the current controller software
(managed by HEIDENHAIN)
