HEIDENHAIN iTNC 530 219
7.1 Processing DXF Files (Software Option)
Opening a DXF file
U Select the Programming and Editing operating mode
U Call the file manager
U In order to see the soft-key menu for selecting the file
type to be displayed, press the SELECT TYPE soft key
U In order to show all DXF files, press the SHOW DXF
soft key
U Select the directory in which the DXF file is saved
U Select the desired DXF file, and load it with the ENT
key. The TNC starts the DXF converter and shows the
contents of the DXF file on the screen. The TNC
shows the layers in the left window, and the drawing
in the right window.
