HEIDENHAIN iTNC 530 29
10.1 Entering Miscellaneous Functions M and STOP ..... 302
Fundamentals ..... 302
10.2 Miscellaneous Functions for Program Run Control, Spindle and Coolant ..... 303
Overview ..... 303
10.3 Miscellaneous Functions for Coordinate Data ..... 304
Programming machine-referenced coordinates: M91/M92 ..... 304
Activating the most recently entered datum: M104 ..... 306
Moving to positions in a non-tilted coordinate system with a tilted working plane: M130 ..... 306
10.4 Miscellaneous Functions for Contouring Behavior ..... 307
Smoothing corners: M90 ..... 307
Insert rounding arc between straight lines: M112 ..... 307
Do not include points when executing non-compensated line blocks: M124 ..... 308
Machining small contour steps: M97 ..... 309
Machining open contours corners: M98 ..... 311
Feed rate factor for plunging movements: M103 ..... 312
Feed rate in millimeters per spindle revolution: M136 ..... 313
Feed rate for circular arcs: M109/M110/M111 ..... 314
Calculating the radius-compensated path in advance (LOOK AHEAD): M120 ..... 315
Superimposing handwheel positioning during program run: M118 ..... 317
Retraction from the contour in the tool-axis direction: M140 ..... 318
Suppressing touch probe monitoring: M141 ..... 319
Delete modal program information: M142 ..... 320
Delete basic rotation: M143 ..... 320
Automatically retract tool from the contour at an NC stop: M148 ..... 321
Suppress limit switch message: M150 ..... 322
10.5 Miscellaneous Functions for Laser Cutting Machines ..... 323
Principle ..... 323
Output the programmed voltage directly: M200 ..... 323
Output voltage as a function of distance: M201 ..... 323
Output voltage as a function of speed: M202 ..... 324
Output voltage as a function of time (time-dependent ramp): M203 ..... 324
Output voltage as a function of time (time-dependent pulse): M204 ..... 324
10 Programming: Miscellaneous Functions ..... 301
