596 Tables and Overviews
18.3 Technical Information
Actual position capture îš„ Actual positions can be transferred directly into the NC program
Program verification graphics
Display modes
Graphic simulation before program run, even while another program is being run
îš„ Plan view / projection in 3 planes / 3-D view
îš„ Magnification of details
Programming graphics îš„ In the Programming and Editing mode, the contours of the NC blocks are drawn on
screen while they are being entered (2-D pencil-trace graphics), even while another
program is running
Program Run graphics
Display modes
îš„ Graphic simulation of real-time machining in plan view / projection in 3 planes /
3-D view
Machining time îš„ Calculating the machining time in the Test Run mode of operation
îš„ Display of the current machining time in the Program Run modes
Returning to the contour îš„ Mid-program startup in any block in the program, returning the tool to the calculated
nominal position to continue machining
îš„ Program interruption, contour departure and return
Datum tables îš„ Multiple datum tables
Pallet tables îš„ Pallet tables (with as many entries as desired for the selection of pallets, NC programs
and datums) can be machined workpiece by workpiece or tool by tool
Touch probe cycles îš„ Calibrate touch probe
îš„ Compensation of workpiece misalignment, manual or automatic
îš„ Datum setting, manual or automatic
îš„ Automatic workpiece measurement
îš„ Cycles for automatic tool measurement
îš„ Cycles for automatic kinematics measurement
Specifications
Components îš„ MC 6241 or MC 6222 main computer
îš„ CC 6106, 6108 or 6110 controller unit
îš„ Keyboard
îš„ 15.1-inchor 19-inch TFT color flat-panel display with soft keys
Program memory At least 21 GB,
Input resolution and display
step
 Up to 0.1 µm for linear axes
 Up to 0.0001° for angular axes
Input range  Maximum 99 999.999 mm (3.937 inches) or 99 999.999°
User functions
