HEIDENHAIN MANUALplus 4110 Linear Machining Example 7.30
Create the “Threaded stud” cycle program
Run the cycle.
Set the feed rate override
feed rate override to 0%
Activate Cycle Start
(The threading tool is not yet
confirmed.)
Confirm tool T8 with the
Tool change key
Activate Cycle Start again
Slowly increase the feed
rate override. The
threading cycle is
performed.
Check the thread and correct the tool, if necessary.
The threading cycle is finished:
Retract with the handwheel
Measure the thread
Thread paths are always machined at the programmed feed rate (thread pitch),
regardless of the current feed-rate override.
