3 Installation of the drive set
CargoPower installation and operation, revision - 01 9
3.2 Installation of the motor
Installation of the drive system in vehicles that are not sufficiently stable
can cause load-bearing parts to break during operation! This may result in
a fall!
˃ Install CargoPower motor RN 111 only in forks and frames,
which can withstand use with electric auxiliary drive up to at least
113 Nm!
Danger due to unforeseen motor activity and rotating parts
The motor may start moving unexpectedly if the drive system is left on
while working on the vehicle. Limbs or clothing may be drawn into
rotating parts. This can result in injuries.
˃ Remove the battery before any work on the vehicle.
˃ When putting the vehicle back into operation after assembly or
repair, position it so that the drive wheel can rotate freely. Only then
reinsert the battery and check the proper function of the drive.
The stub axle is only provisionally pre-mounted on the CargoPower
motor RN111 at the factory! It must be fastened with suitable axle stub
screws from HEINZMANN before installing the motor.
(art. no. 001-01-030-21, TORX®).
Tightening torque: 8.5 Nm +1.2 Nm
Tightening torque of the wheel nuts of the drive wheel during installation:
45 Nm ± 5 Nm (for M10×1)
for other thread sizes see technical drawing
When installing a front wheel motor, a washer must always be
mounted on the axle between the motor and the dropout on its
A-side!
