8 Spoking the CargoPower motor RN 111
CargoPower installation and operation, revision - 01 67
8.4.3 Spoke pattern for rear wheel, rim 26" or rim 28", 1× crossed
When spoking in CargoPower motors RN 111 applies as rear wheel drive in rims 26" or
28":
- all spokes are guided through both flanges from the B-side (= side of the brake
disk). All spoke heads point towards the brake disk.
- Spokes are crossed 1× (cf. fig.).
Fig. 4.1 Spoke pattern rear wheel, rim 26" or rim 28", 1× crossed
