8 Spoking the CargoPower motor RN 111
CargoPower installation and operation, revision - 01 64
8 Spoking the CargoPower motor RN 111
An incorrectly or improperly stored rim can lead to wheel failure and thus
accidents.
˃ Spoking the motor into a rim may only be carried out by expert
personnel!
8.1 Rims
Only rims with 36 spoke holes can be used.
Punched and eyeleted hollow section rims with french hole pattern and obliquely drilled
spoke holes are recommended.
8.2 Spoke diameter
Bore diameter of the spoke holes in the flanges of RN 111,
see technical drawings
880-00-180-* Rear wheel CargoPower motor, HR
880-00-181-* Front wheel CargoPower motor, VR
880-00-182-* Single-sided suspension CargoPower motor, EA
8.3 Spoke lengths
The specification of binding spoke length is not easily possible.
The required length of the spokes depends on:
- Position of the plane of the rim center in relation to the flanges of the motor
- the effective diameter of the rim (ERD)
From these values and the dimensions of the motor, the user must determine the required
spoke lengths.
Before spoking, obligatory check the correct bolt circle diameter on the basis of
the Check the correct bolt circle diameter against the corresponding technical
drawing of the motor and measure again at the motor flange.
