3 Installation of the drive set
CargoPower installation and operation, revision - 01 13
3.2.4 Brake disk initial assembly and change
View of the assembled motor
Item no.: 880-00-18X-XX
Disassembly the M6 bolts securing the stub
axle.
Di
sassembled screws must not
be reused for assembly.
To disassembly the stub axle and torque arm,
use an impact puller
. Without it, there is a
risk of damaging the pin holes during
disassembly.
An impact extractor is
HEINZMANN.
Item no.: 880-80-303-00
View of the motor, stub axle and torque arm
disassembled.
