HellermannTyton Autotool 2000 CPK - Synchronising Time and Date; Display Binding Information; Select Parameter Set; Set Interruption Front Sensor

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
HT Data Management
19
9.3.3 Synchronising time and date
f Click on Synchronise with PC time
5 .
; Clock time and date of the power pack are synchronised
with the PC connected to the device.
Time and date are saved in the power pack and have to be
rechecked if the power pack is subsequently replaced.
9.3.4 Display binding information
Binding information
7 shows the process data of the
last binding performed with the connected AT2000 CPK.
9.3.5 Select parameter set
In the parameter sets, preset values are grouped and
transferred to the AT2000 CPK, à"Parameter set
menu" on page27
f Select a configured parameter set in the Parameter set
8 field.
; The changed parameters are transferred to the AT2000
CPK.
9.3.6 Set interruption front sensor
The Interruption front sensor setting
9 enables you to
decide how long the level sensor can remain busy
without the Error, front cap message appearing on the
display, à"Display messages" on page30.
f Select the level in the Interruption front sensor
9 field.
; There are five levels:
• Level 1: 0.0 seconds
• Level 2: 0.3 seconds
• Level 3: 0.5 seconds
• Level 4: 0.7 seconds
• Level 5: 0.9 seconds
; The setting is changed and transferred to the AT2000
CPK.
9.3.7 Setting the binding check
The Check of binding setting
10 enables you to decide
whether or not the Error, binding force message
appears on the display, à"Display messages" on
page30
f Set the binding in the Check of binding
10 field,
à"Check of binding" on page16. The following
options are available:
• OFF
• Error notification
• Acknowledgement
; The setting is changed and transferred to the AT2000
CPK.
9.3.8 Activating consecutive trigger
Consecutive trigger
11 effects continuous binding
without repeatedly actuating the start trigger. Bindings
will be carried out as long as the start trigger remains
pressed.
f Activate the consecutive trigger
11 .
9.3.9 Status indicators
The Tool Status
12 field displays the operating status of
the AT2000 CPK.
Colour Status
Connection to the
power pack CPK
Green Connection active
Red Error message active
Grey No connection / connection
interrupted
Connection to
AT2000 CPK
Green Connection active
Red Error message active
Grey No connection / connection
interrupted
Status of the
AT2000 CPK
Green Ready
Yellow Busy
Blue Main menu on AT2000 CPK active
Binding not possible
Red Error message active
Grey No connection / connection
interrupted
