Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
HT Data Management
22
9.5.3 Limit the time period of the messages
Limits the time period for updating the messages
3 .
It is advisable to set a filter to restrict the choice if the volume
of data involved is large.
f Activate Limit messages 3 .
f In the drop-down menus Export from and Export until,
select the start and end dates for the export period.
f Click on Export
6 .
9.5.4 Select bindings
Select the bindings to be exported. The data exported
contain the information about the individual bindings.
It is advisable to set a filter to restrict the choice if the volume
of data involved is large.
f In the fields From binding No. 5 and To binding
No. 5 , restrict the quantity of bindings for export.
f Click on Export
6 .
9.5.5 Select messages
Select the messages to be exported. The data exported
contain the errors or messages.
It is advisable to set a filter to restrict the choice if the volume
of data involved is large.
f In the fields From message No. 4 and To message
No. 4 , restrict the messages for export.
f Click on Export
6 .
9.5.6 Read and export the process data on the
HTDM
The data are not deleted after they have been exported.
A Data elds have not been initialised
message is issued if the process data have not been
refreshed.
f If required, restrict the amount of data for export.
f Click on the Refresh button
1 .
f Click on Export
6 .
f Define the storage location for the exported *.CSV data.
f In the window opened by the operating system, click on
the Save button.
; The bindings and messages are exported from the
AT2000 CPK and saved as a *CSV file.
; The progress bar shows progress of the data transfer in
percent (%).
; When export completes the name of the saved file
appears in File loaded.
9.5.7 Export data
There are two export formats:
• XLS: The saved *.XLS file can be opened using a table
calculation program.
• HTML: The saved *-HTML file can be opened using the
browser, à"Display exported data in the HTML format"
on page22.
f Click on Source file
7 and select the exported file in the
dialogue window of the operating system.
f The file appears in File loaded.
f Select the export format for the file.
9.5.8 Display exported data in the HTML format
The exported data is displayed in the browser in three
categories:
• Start page (information on the model and serial number
of the AT2000 CPK as well as the counter readings)
• Production data (information on the parameter set,
temperature, power, cycle time, etc. for each binding)
• Messages (information on messages and time of
occurrence)
f The exported HTML file can be opened with an up-to-
date browser.
f Click on the category button in order to display the
category.
f Click on the pictogram of the country flag in order to
switch the data display language to English.
