2.6 Fan Description
Figure 21: Fan Description
The Fan Modules are toolless internal fans that provide the primary cooling for the Ultrastar Serv24-HA. The
fan are installed inside the compute canister in close proximity to the compute canister components to provide
efficient cooling to all of the drives. Each compute canister contains five fans, two in the middle and three near
the rear of each canister.
2.6.1 Fan Specification
Table 22: Fan Specification Summary
ValueSpecification
10 (five per compute canister)Number Per Enclosure
1EX1046Part Number
NoHot Swappable?
.13 kg / .3 lbsWeight
31
2 Component Overviews
User Guide 2.6 Fan Description
