The Web UI will appear.
Figure 44: Web UI
b) In the Web UI, click Dashboard.
The Dashboard Control Panel page will appear.
Figure 45: Dashboard Control Panel
c) Review the Dashboard Control Panel to identify that there are no failures reported.
3.4 CPU and Heat Sink Module Replacement
Table 32: Replacement Procedure Info
Time Required# of People RequiredRequired Tools
20 minutes1T30 Torx screwdriver
1. Identify the failed CPU.
a) Open a browser and browse to the BMC IP Address of the Compute Canister.
43
3 Part Replacement
User Guide 3.4 CPU and Heat Sink Module Replacement
