Battery Backup, and M.2 Boot Drives are all contained in each of the Compute Canisters. The redundancy
of the Compute Canisters is designed so that the system can run on one canister in the event that the other
canister fails. The Compute Canisters can be hot-swapped to ensure that the enclosure is always available.
2.7.1 Compute Canister Specification
Table 24: Compute Canister Specification Summary
ValueSpecification
2Number Per Enclosure
1EX1049Part Number
YesHot Swappable?
9.34 kg / 20.6 lbsWeight
2.7.2 Compute Canister Layout
Figure 24: Compute Canister Layout
2
1
2
3
4
3
Table 25: Compute Canister Layout
FeatureNumber
Compute Canister Connectors1
Cover Release Buttons2
Canister Release Latches3
Rear I/O4
33
2 Component Overviews
User Guide 2.7 Compute Canister Description
