The Web UI will appear.
Figure 71: Web UI
b) In the Web UI, click Dashboard.
The Dashboard Control Panel page will appear.
Figure 72: Dashboard Control Panel
c) Review the Dashboard Control Panel to identify that there are no failures reported.
3.6 M.2 Boot Drive Replacement
Table 34: Replacement Procedure Info
Time Required# of People RequiredRequired Tools
12 minutes1None
Attention: The compute canister contains a total of two M.2 boot drives, with a total of four per enclosure.
Only one set of drives may be changed at a time. If both compute canisters contain drives that have
failed, replace the drive in the first canister completely before removing and replacing the remaining
failed drive in the second compute canister.
61
3 Part Replacement
User Guide 3.6 M.2 Boot Drive Replacement
