The Web UI will appear.
Figure 56: Web UI
b) In the Web UI, click Dashboard.
The Dashboard Control Panel page will appear.
Figure 57: Dashboard Control Panel
c) Review the Dashboard Control Panel to identify that there are no failures reported.
3.5 Heat Sink Replacement
Table 33: Replacement Procedure Info
Time Required# of People RequiredRequired Tools
30 minutes1• Torx T30 Screwdriver
• Spudger
1. Identify the failed Heat Sink.
a) Open a browser and browse to the BMC IP Address of the Compute Canister.
51
3 Part Replacement
User Guide 3.5 Heat Sink Replacement
