b) Carefully slide the Compute Canister into the slot with both latch handles in the open position until
the latch handles begin to engage.
Figure 54: Installing the Compute Canister
c) Rotate the latch handles into the enclosure until the are fully engaged.
Figure 55: Latching the Compute Canister
10. Verify that the CPU appears with no issues.
a) Open a browser and browse to the BMC IP Address of the Compute Canister.
50
3 Part Replacement
User Guide 3.4 CPU and Heat Sink Module Replacement
