HIKVISION DS-2CD6986F-H User Manual

User Manual of PanoVu Series Network Camera
69
(4) After setting the arming schedule, you can click a segment to display the segment arming
settings interface to edit the segment record parameters (optional).
Figure 6-5 Segment Arming Settings
(5) Click to save the settings.
Note:
The time of each period cannot be overlapped. Up to 8 periods can be configured for each
day.
6. Set the Alarm Actions for Motion Detection.
Click tab to enter the Linkage Method interface.
You can specify the linkage method when an event occurs. The following contents are about
how to configure the different types of linkage method.
Figure 6-6 Linkage Method
Check the checkbox to select the linkage method. Send Email, Notify Surveillance Center,
Upload to FTP/Memory Card/NAS, Trigger Alarm Output and Trigger Recording are selectable.
 Send Email
Send an email with alarm information to a user or users when an event occurs.
Note:
 To send the Email when an event occurs, you need to refer to Section 2.2.2 Advanced
Settings - Configuring Email Settings to set the Email parameters.
 Notify Surveillance Center
Send an exception or alarm signal to remote management software when an event occurs.
 Upload to FTP/Memory Card/NAS
Capture the image when an alarm is triggered and upload the picture to a FTP server.
