Network Video Recorder User Manual
98
Figure 8-9 Testing Result of Network Delay and Packet Loss
8.5.2 Export Network Packet
The captured network data packet can be exported to USB flash drive, or other local backup
devices.
Steps
1. Go to Menu → Maintenance → Net Detect → Network Detection.
2. Select a backup device in Device Name.
Note
Click Refresh if the connected local backup device cannot be displayed. When it fails to detect
the backup device, please check whether it is compatible with the device. You can format the
backup device if the format is incorrect.
Figure 8-10 Export Network Packet
3. Click Export to start exporting.
4. Click OK after the exporting is completed.
Note
Up to 1 MB data can be exported each time.
8.5.3 Check the Network Status
You can check your network status, and quickly set the network parameters if the network is
abnormal.
Go to Menu → Maintenance → Net Detect → Network Detection. Click Status at the lower- right
corner.
