HIKVISION DS-K1T803MF User Manual

Fingerprint Access Control Terminal
89
Check the select the card reader of the access control point and set the start date and the end date.
Select the check point type.
Click to save the adding.
The added check points will be displayed in the attendance check point list.
3. You can check the checkbox of a check point, and click to pop up the attendance check
point editing window.
You can edit the attendance check point name, start date, end date, and check point type, controller
name, door position, and card reader name.
Click to complete the operation.
4. You can check the checkbox of a check point and click to delete the added check point.
5.4.6 Adjustment Management
Click the Adjustment tab to enter the adjustment management interface.
In this module, Reason Management and List Management can be realized.
Reason Management
 Leave
You can add, edit, and delete reasons for leave on the leave interface.
Steps:
1. Click Leave tab to enter the leave interface.

HIKVISION DS-K1T803MF Specifications

General

Type	Basic access control reader
Product color	Black
Cards capacity	3000 cards
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
Fingerprint sensor type	Optical
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
Contactless working distance	50 mm
International Protection (IP) code	IP42
PC connected	-
Ethernet LAN data rates	10, 100 Mbit/s
Display type	TFT-LCD
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Front camera	No
DC current (max)	1 A

Weight and Dimensions

Depth	37 mm
Width	76.5 mm
Height	205 mm
