HIKVISION DS-K1T803MF User Manual

Fingerprint Access Control Terminal
59
Several ways are supported to delete the access control point, as shown below.
 Click to select a group in the group list, select door(s) under it, and click button.
 Click to select a group in the group list, and click button to delete all access control
points under the group.
 Move the mouse onto a group in the group list, and click button to delete all access control points
under the group.
Note: you can also edit/delete a door on the Import Access Control Point panel.
Steps:
1. Select a control point on the Group panel.
2. Click the / icon to enter the Edit Access Control Point panel or to delete the control point.
Permission Management 5.3
5.3.1 Person Management
Click the icon on the control panel of the software.
Adding, editing, deleting and filtering of the department and person are supported in this interface.
Department Management
Steps:
1. In the department list, click button to pop up the adding department interface.

HIKVISION DS-K1T803MF Specifications

General

Type	Basic access control reader
Product color	Black
Cards capacity	3000 cards
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
Fingerprint sensor type	Optical
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
Contactless working distance	50 mm
International Protection (IP) code	IP42
PC connected	-
Ethernet LAN data rates	10, 100 Mbit/s
Display type	TFT-LCD
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Front camera	No
DC current (max)	1 A

Weight and Dimensions

Depth	37 mm
Width	76.5 mm
Height	205 mm
