HIKVISION DS-K1T803MF User Manual

Fingerprint Access Control Terminal
8
Terminal Description Table 3. 1
Line
Group
No.
Function
Color
Terminal
Name
Description
Line
Group A
A1
Power Input
Red
+12V
12V DC Power Supply
A2
Black
GND
GND
Line
Group B
B1
Alarm Input
Yellow/Blue
IN1
Alarm Input 1
B2
Yellow/Black
GND
GND
B3
Alarm Output
Yellow/Purple
NC
Alarm Output Wiring
B4
Yellow/Brown
COM
B5
Yellow/Red
NO
Line
Group C
C1
RS-485
Communication
Port
Yellow
485 +
RS-485 Wiring
C2
Blue
485 -
C3
Wiegand
Green
W0
Wiegand Wiring 0
C4
White
W1
Wiegand Wiring 1
C5
Orange
WG_OK
Wiegand
Authenticated
C6
Purple
WG_ERR
Wiegand
Authentication Failed
C7
Brown
WG_ BEEP
Tampering Alarm
Wiring
C8
Grey
WG_TAMP
ER
Buzzer Wiring
C9
Black
GND
GND
Line
Group D
D1
Lock
White/Purple
NC
Lock Wiring
D2
White/Yellow
COM
D3
White/Red
NO
D4
Yellow/Green
SENSOR
Door Contact Signal
Input
D5
White/Black
GND
GND
D6
Yellow/Grey
BUTTON
Exit Door Wiring
Line
Group E
E1
Door Bell
White/Brown
BELL+
Door Bell Wiring
E2
White/Blue
BELL-

HIKVISION DS-K1T803MF Specifications

General

Type	Basic access control reader
Product color	Black
Cards capacity	3000 cards
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
Fingerprint sensor type	Optical
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
Contactless working distance	50 mm
International Protection (IP) code	IP42
PC connected	-
Ethernet LAN data rates	10, 100 Mbit/s
Display type	TFT-LCD
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Front camera	No
DC current (max)	1 A

Weight and Dimensions

Depth	37 mm
Width	76.5 mm
Height	205 mm
