Wireless LAN – WLAN
BAT54-Rail/F..
Release
7.54
06/08
3.4
Configuration of WLAN parameters
63
This group includes two other parameters in addition to the country setting:
ARP handling
D Mobile stations in the wireless network that are on standby do not answer
the ARP requests from other network stations reliably. If 'ARP handling' is
activated, the access point takes over this task and answers the ARP re-
quests on behalf of stations that are on standby.
Broken link detection
D The 'Broken link detection' deactivates the WLAN card if the access point
loses contact to the LAN.
Configuration with WEBconfig or Telnet
Under WEBconfig or Telnet you will find the general WLAN parameters un-
der the following paths:
3.4.3 WLAN routing (isolated mode)
When set by default the data between LAN and WLAN is transmitted trans-
parently. Thereby the data transmission between cabled and radio network
does not pass over the IP Router. This means, that the features firewall and
Quality of Service integrated in the IP router are not provided for transferring
data between WLAN and LAN. To use these options nevertheless, the
WLAN interface can be set to “isolated mode”, so the data is transferred de-
liberately over the IP router.
Note: So the IP router can transfer data between LAN and WLAN correctly,
both areas must have different IP address sections and the local routing
must be activated in the IP router settings.
Configuration tool Menu/Table
WEBconfig Expert-Configuration
Setup WLAN
Terminal/Telnet
cd /Setup/WLAN
