Hitron CGNV4 User’s Guide
The following table describes the labels in this screen.
Table 9: The Status: DOCSIS WAN Screen
DOCSIS Overview
Network Access This displays whether or not your service provider
allows you to access the Internet over the CABLE
connection.
Permitted displays if you can access the Internet.
Denied displays if you cannot access the Internet.
IP Address This displays the CGNV4’s WAN IP address. This IP
address is automatically assigned to the CGNV4
Subnet Mask This displays the CGNV4’s WAN subnet mask.
DHCP Lease Time This displays the time that elapses before your device’s
IP address lease expires, and a new IP address is
assigned to it by the DHCP server.
Downstream Overview
NOTE: The downstream signal is the signal transmitted to the CGNV4.
Force Downstream
Frequency (MHz)
Use this to configure the CGNV4 to use a specific
downstream frequency. Enter the desired frequency in
Megahertz (MHz) and click Apply.
Port ID This displays the ID number of the downstream
connection’s port.
Frequency (Hz) This displays the actual frequency in Hertz (Hz) of each
downstream data channel to which the CGNV4 is
connected.
Modulation This displays the type of modulation that each
downstream channel uses.
Signal Strength
(dBmV)
This displays the power of the signal of each
downstream data channel to which the CGNV4 is
connected, in dBmV (decibels above/below 1 millivolt).
Signal Noise Ratio
(dB)
This displays the Signal to Noise Ratio (SNR) of each
downstream data channel to which the CGNV4 is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the downstream signal is transmitted.
Upstream Overview
NOTE: The upstream signal is the signal transmitted from the CGNV4.
