Hitron CGNV4 User Manual

Version 1.1, 02/2014. Copyright 2012 Hitron Technologies
38
Version 1.1, 02/2014. Copyright 2014 Hitron Technologies
38
Hitron CGNV4 User’s Guide
2.5 The DOCSIS Event Screen
Use this screen to view information about local WAN activity events.
Click Status > DOCSIS Event. The following screen displays.
Force Downstream
Frequency (MHz)
Use this to configure the CGNV4 to use a specific
upstream frequency. Enter the desired frequency in
Megahertz (MHz) and click Apply.
Port ID This displays the ID number of the upstream
connection’s port.
Frequency (Hz) This displays the actual frequency in Hertz (Hz) of each
upstream data channel to which the CGNV4 is
connected.
Modulation This displays the type of modulation that each upstream
channel uses.
Signal Strength
(dBmV)
This displays the power of the signal of each upstream
data channel to which the CGNV4 is connected, in
dBmV (decibels above/below 1 millivolt).
Signal Noise Ratio
(dB)
This displays the Signal to Noise Ratio (SNR) of each
upstream data channel to which the CGNV4 is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the upstream signal is transmitted.
Table 9: The Status: DOCSIS WAN Screen (continued)

Hitron CGNV4 Specifications

General

Wi-Fi Standard	802.11n
Frequency Bands	2.4 GHz, 5 GHz
Ethernet Ports	4
USB Ports	1
DOCSIS Version	3.0
Downstream Channels	24
Upstream Channels	8
Type	Cable Modem Router
Max Download Speed	960 Mbps
Max Upload Speed	240 Mbps
Security Features	WPA, WPA2
Wi-Fi Frequency	2.4 GHz
