Hitron CGNV4 User Manual

Version 1.1, 02/2014. Copyright 2012 Hitron Technologies
49
Version 1.1, 02/2014. Copyright 2014 Hitron Technologies
49
Hitron CGNV4 User’s Guide
Disabling the residential gateway feature sets the unit to use bridge mode only. Use
this mode when your network is already using another router.
Click Basic > Gateway Function. The following screen displays.
Figure 14: The Basic: Gateway Function Screen
The following table describes the labels in this screen.
3.4 The Port Forwarding Screen
Use this screen to configure port forwarding between computers on the WAN and
computers on the LAN. You can turn port forwarding on or off and configure new and
existing port forwarding rules.
Click Basic > Port Forwarding. The following screen displays.
Table 14: The Basic: Gateway Function Screen
Residential Gateway
Function
Select the checkbox to enable the CGNV4’s residential
gateway features, or deselect the checkbox to disable
them.
UPnP IGD Select the checkbox to enable the CGNV4’s Universal
Plug n Play Internet Gateway Device features, or
deselect the checkbox to disable them.

Hitron CGNV4 Specifications

General

Wi-Fi Standard	802.11n
Frequency Bands	2.4 GHz, 5 GHz
Ethernet Ports	4
USB Ports	1
DOCSIS Version	3.0
Downstream Channels	24
Upstream Channels	8
Type	Cable Modem Router
Max Download Speed	960 Mbps
Max Upload Speed	240 Mbps
Security Features	WPA, WPA2
Wi-Fi Frequency	2.4 GHz
