1 Add & ID RF Devices

1 RF Zone Opts

1 Locate: RF Zone

1 Remove: RF Zone

Z01 Zone 1

2 RF Keyfob Opts

2 Locate: RF Keyfob

2 Remove: RF Keyfob

Z02 Zone 2

2 Locate RF Devices

3 Remove RF Devices

4 RF Device Options

• Go to the Devices Menu. Then RF Devs Menu. Next select the RF Device Options.

• Go to the Devices Menu. Then RF Devs Menu. Next select the Locate RF Devices.

• Go to the Devices Menu. Then RF Devs Menu. Next select the Remove RF Devices.

• The RF-Smoke’s one and only programmable option can be accessed as follows;

• The RF-Smoke can be located as follows;

• The RF-Smoke can be removed as follows;

• From there go to RF Zone Opts and then select the RF-Smoke number in question.

• The only option is Mon Sup (Monitored Supervisory signal) which is defaulted to YES. When the device is

“lost” for a prolonged period of time, a supervisory alarm is flagged by the panel. This can be turned off by

selecting NO. However, we recommend that this feature is left as YES

• From there go to Locate: RF Zone and then select the RF-Smoke number in question.

• The LED on the RF-Smoke that you selected will flash on and off every second thus helping you to locate it.

• Also note, pressing the switch on a device will locate and display said device at the keypad.

• From there go to Remove: RF Zone and then select the RF-Smoke number you want removed. Press YES to

select this device for removal and press YES again to confirm removal.

2 Devices Menu

2 Wired Devices Menu

1 RF Devices Menu

1 Service Menu

3 Zone Menu

Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)

RF-SD (Smoke Detector) - Continued
