Zone Wiring
DUAL END OF LINE WIRING
Single Detector e.g. PIR with only 4-core cable
Most commonly used within the industry
Usually for retrofit in a previous EOL system
Note: Requires only 2 wires (+ 2 power for PIR)
SENSORS 1.. 10
TAMPERS 1.. 10
4K7
4K7
RED
RED
BLACK
BLACK
YELLOW
YELLOW
Multiple Detectors e.g. Inertia Sensors
Note: Additional return wire required
4K7
4K7
RED
YELLOW
ALARM
TAMPER
STANDARD WIRING SINGLE END OF LINE WIRING
SENSORS 1.. 10
TAMPERS 1.. 10
RED
BLUE
BLACK
YELLOW
SENSORS 1.. 10
TAMPERS 1.. 10
4K7
RED
BLUE
BLACK
YELLOW
ZONE 1 TAMPER 1
ZONE 1 TAMPER 1
ZONE 1 TAMPER 1
ZONE 1 TAMPER 1
Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)
Your Quantum Control Panel comes with a traditional hardwired zone input - Zone 1.
By default this is shipped as a non-EOL (end-of-line) input.•
• The other EOL options are Single EOL and Dual EOL. Please see the wiring diagrams below.
• If you have already mapped a wireless detector on to Zone 1 it cannot be used as a hardwired input unless
you remove that wireless device and map it on to another zone number instead.
1 Zone Names
2 Zone Types
3 Zone Options
4 Zone Gross & Pulse
5 Zone Hardware
6 Zone Block Assign
7 Technical Zone Options
2 Non EOL
3 Single EOL
4 Dual EOL
5 Point ID
1 RF Device
2 Devices Menu
1 Service Menu
3 Zone Menu
43
