Technical Specifications
Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)
Power Supply (Type A)
Rated Supply
Battery
Product Weight
Size
Housing Material
Mains Fuse
Logical Keys
Security Grade
Temperature / Humidity
Mains Input: 150mA, 230Vac +10%/-15%, 50Hz
SMPS Output: 10Vdc to 13.8Vdc. Rated to deliver 1.5A max.
Aux. output (limited by 350mA fuse): 50mA / 13.8Vdc max to 8.2Vdc min
HHHC252C, 9.6V, 2,400mAh, NiMH
Max. recharge time 14h
1,210g
302mm x 190mm x 52mm
Polycarbonate
3.15A (T) High Breaking Capacity 20x5mm
Number of variations is 472,391 - i.e. with 6 digits ((9x9x9x9x9x8)-1)
Note: 0 is disallowed in all digits & 9 is disallowed in the last digit only
if the Duress feature is enabled. Codes can be 4 to 6 digits in length.
A Code Tamper event is triggered after 7 failed code entry attempts.
EN 50131-1:2006 +A1:2009 Grade 2
-10°C to +40°C / 75% non-condensing (Class II)
Outputs
STROBE & EXT BELL outputs both limited with 750mA fuses
Current Consumption
Max. number per system
Panel: 90mA quiescent, 300mA (peak) alarm
SABB: 40mA quiescent, 360mA (peak) alarm
ID Sensor: 2mA quiescent, 5mA alarm
PIR: 9.5mA quiescent, 8.5mA alarm
GSM-Q: 20mA quiescent, 140mA transmit
GSM-WiFi: 30mA quiescent, 70mA max.
RF-Keyfob: 32 (i.e. 1 per User Code)
Prox Tag
Point ID Devices: 10
SABB: 1
RF-SABB: 2
RF-ECHO: 2
GSM-Q/WiFi 1
RF-RKP: 1
RF Detectors: 70
: 32 (i.e. 1 per User Code)
Cabling
(standard alarm cable)
Panel to SABB; 50m
Note: put SABB into SCB mode
Panel to remote device on Point ID bus;
200m Total cable on Point ID bus; 600m
Zone
Auto-inhibit
Non-volatile memory
Indications
Zone has Inertia Sensor analysis
single-EOL and dual-EOL resistance. EOL resistor = 4k7Ω.
Response = 300ms
Zone is configurable for non-EOL,
By default, multiple activations on a zone will re-tigger the siren(s)
a maximum of 3 times and be logged a maximum of 10 times.
Level specific indications (as detailed in clause 8.5 in EN 50131) are typically
time limited or can be cancelled by pressing QUIT.
NVM data is stored in a flash device that has more than 20 years data
retention with ability to execute more 100,000 erase/program cycles
per sector.
All signal processing, whether by WD or ARC is done on a “first come, first
served” basis.
Signal Prioritisation
90
