921 DTV MODULE
92 COMMUNICATORS
91 COMMS OVERVIEW
Gives a quick overview of real time conditions for instance
whether the telephone line has a fault.
By default the dialer is disabled. This saves power. As soon
as you attempt to program the dialer you will be prompted to
enable the dialer.
The Line Mon Menu has three sections:
Line Mon On (Line Monitor On) enables the line monitor
circuitry.
OH Monitor (Off-Hook Monitor) enables off-hook detection
circuitry to generate a line fault if the line voltage falls below
15Vdc. Line voltage is nominally 48Vdc.
OH-LF(Unset) (Off-Hook Line Fault when Unset), if disabled,
will not generate a line fault when the phone line is off-hook
and when the panel is unset. When the panel is set and the
phone is off-hook a line fault will be generated
The Dial Opts Menu has two sections:
In Dial Tone, each phone can be individually enabled, by
selecting YES, to wait for a dial tone before the digi proceeds
to make a call. They are all set to YES by default.
In PABX Prefix, if you key-in a number, it will put at the start
of the pre-programed phone numbers. For example, if a pre-
programed phone number is 014567007 and the PABX Prefix
is 9 then the digi will dial 9014567007.
Note1: There will be a 3 second pause between the PABX Prefix and the rest
of the phone number.
Note2: The system knows to drop the PABX Prefix if the call is routed via the
GSM network instead.
Note3: If you want to clear the number in PABX Prefix, press NO.
1 STATUS
2 DISABLE DIALER
3 OPTIONS
31 Line Mon Menu
32 Dial Opts Menu
33 Incoming Call Opts
34 SMS Opts Menu
!
!
!
Comms Menu
75
Gives a quick overview of how the landline dialler, GSM
dialler and SMS feature has been configured and highlights if
any option has been selected that might lead to confusion
during system test i.e. How the channels are programmed,
whether text is enabled etc.
Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)
