Devices Menu - Continued
22 WIRED DEVICES MENU
222 Locate Points
223 Remove Points
221 Add & ID Points
Add & ID Points is used to add Point ID devices to the
Point ID bus on Zone 1. Follow the prompts on the display.
Locate Points, this menu is used to locate a Point ID
device that has been assigned an ID. A device can be
located by selecting it in this menu and noting its LED
pattern.
Remove Points, this menu is used to remove a Point ID
device from the system. Only a device that has been ID’ed
can be removed from the system.
Note: See pages 38 and 39 for more information
Default Eng. Code - 4567 Default User Code - 1111 (Irl) 1234 (UK)
52
!
21 RF DEVICES MENU
contd.
If the alarm system is set-up with SecureComm, has the
HKC app and an RF-PIRCAM unit, you can avail of the RF
Camera Options. There are 4 sections in this sub-menu...
Image Size is defaulted to VGA which is 640x480 pixels. If
you press YES you can toggle to QVGA which has a lower
resolution of 320x240 pixels but has a quicker transmission
time.
Color is defaulted to YES. You can select black and white
by pressing NO but unless there are specific site-related
reasons for choosing black and white we recommend
keeping the colour on.
Num images is shorthand for “Number of images” and is
defaulted to 3. When the system is armed and the PIRCAM
is triggered, 3 snapshots are taken in 1 second intervals.
This number can be changed by pressing YES and then
pressing any number between 1 to 5.
•
Live images is defaulted to
NO. When YES is selected, you can take a snapshot on
your smart phone whenever you want. When you take a
snapshot, the RF-PIRCAM’s flash will always trigger even if
the flash option is set to NO.
(panel s/w V3.3.4 or higher)
216 RF Camera Options
