The main circuit power supply must be ON.

No alarm has occurred.
 Hardware Base Blocking (HWBB) function must be invalid.

Must in servo OFF state.

The setting of JOG speed must take into account the operating range of the machine used.
Set the JOG speed through the following parameters.
Pn304
Jog (JOG) speed
Speed Position Torque
Setting range
Setting Unit
Factory setting
Effective time
Category
0～10000
1 min
-1
500
Effective
immediately
Setup
Pn305
Soft start acceleration time
Speed
Setting range
Setting Unit
Factory setting
Effective time
Category
0～10000
1 ms
0
Effective
immediately
Setup
Pn306
Soft start deceleration time
Speed
Setting range
Setting Unit
Factory setting
Effective time
Category
0～10000
1 ms
0
Effective
immediately
Setup
7.3.2 Operable tool
The executable operations for JOG operation are as follows
Operating tool
Distribution
Panel operator
Fn002
iWatch+ debugging
software
[JOG Operation]
