HNC Electric HSD7-E Series - Servo Drive Model Description

2
1.3 Model Description
1.3.1 Servo drive model description example
■ Three-phase 220VAC
HSD7
_
ES
_
10
A
00
HSD7 Series
Axis
Number
Continuous Output
Current
Power
Supply Voltage
Interface
Type
Axis Number
Contionous Output Current
Power Supply Voltage
Interface Type
S
Single
03
3.0 A
A
220VAC
00
Analog (standard resolution)/Pulse
Axis
06
6.5 A
08
8.5 A
W
Double
10
10.5 A
01
CANopen Communications
Axis
05
Analog (high resolution )/Pulse
12
12 A
10
MECHATROLINK-Ⅱ
16
16A
Communications
25
25 A
20
MECHATROLINK-Ⅲ
Communications
30
EtherCAT Communications
* The maximum specification of continuous output current for biaxial drive is 10.
■ Three-phase 380VAC
HSD7
--
ES
_
15
D
00
HSD7 Series
Axis
Number
Continuous Output
Current
Power
Supply Voltage
Interface
Type
Axis Number
Contionous Output Current
Power Supply Voltage
Interface Type
S
Single
15
15 A
D
380VAC
00
Analog (standard resolution )/Pulse
Axis
18
18 A
24
24 A
01
CANopen Communications
35
35 A
05
Analog (high resolution)/Pulse
10
MECHATROLINK-Ⅱ
Communications
20
MECHATROLINK-Ⅲ
Communications
30
EtherCAT Communications
* Servo motor model commands refer to the current product selection sample book
