User manual C4 – C6
53
Attachment of winch head
 Remove the winch head from the support on the boom (see figure
64).
Figure: 64
 Secure the boom adapter to the rear of the winch head with the
locking pin. Secure the pin (see figure 65).
Figure: 65
 Connect the winch head with the boom adapter to the boom with
the locking pin. Secure the pin (see figure 66).
Figure: 66
Activating winch operation
 Activate the winch control by pressing the ✓ button on the
remote control (see figure 67).
Figure: 67
 Then open settings by pressing the ✓ button. Then press the
 button to set the winch state to ON (see figure 68).
Figure: 68
