User manual C4 – C6
77
Slide ballast out (see figure 90).
Figure: 90
Take the ballast support out of the storage position and mount and
secure it in the ballast removal position (see figure 91).
Figure: 91
Remove the rear cover of the boom with a 10 mm Allen key (see
figure 92).
Figure: 92
Slide the boom out slightly and switch off the control (see figure
93).
Figure: 93
Attach the ballast removal cable (see figure 94) to the back of the
outermost sliding boom section with a bow shackle (see figure 96).
Figure: 94
Figure: 95
