HollySys LK Series User Manual

Chapter 5 Master Control Unit
Beijing HollySys Intelligent Technologies Co., Ltd. All Rights Reserved 91
LK220 Master Control Module
Rate
115200bps
Protection Rating
Protection Rating
IP20
Hot-swappable
Hot Plug
Support hot-plug of the module and the SD card
Scale of Single System
IO Capacity
IO supported by system is not less than 10,000
points
Configuration Capacity
Input Variable Area (Area I)
The max. space is 128KB
Output Variable Area (Area Q)
The max. space is 128KB
Global Variable Area (Area G)
The max. space is 5MB
Free Variable Areas (Zone M)
The max. space is 5MB
Retain Area (Area R)
The max. space is 64kB
Specified Register Area (Area S)
The space is fixed to be 2KB
Power Supply
Input Voltage
Related to the output of LK921
Module Dissipation (max.)
7.2W
Backup Battery
Based on battery/capacitance power supply
Dual-machine Redundancy
Dual-machine Redundancy
Support dual-machine redundancy
Starting Time
Time from the moment when the module is powered on to the
moment when the user's project begins
≤
40 s
Physical Property
Installation Pattern
Backboard slot
Module Dimension (W*H*D)
44.7 mm*166 mm*152 mm
±
0.5mm
Weight
382 g
5.4 LK249 DP Master Station
Communication Module
LK249 is a DP master station communication module for large-scale PLC of the new-generation LK
Series. The module has 2 DB9 communication interfaces, supporting Hollysys PROFIBUS-DP master
station communication protocol. It can be connected to up to 124 slave stations.
5.4.1 Features
 Support the PROFIBUS-DP master station communication protocol
