HollySys LK Series User Manual

Chapter 6 IO Unit
Beijing HollySys Intelligent Technologies Co., Ltd. All Rights Reserved 109
LK910 24VDC Power Module
Output overvoltage protection
120%~140% rated voltage
Output short circuit protection
Output short circuit fault protection, power automatically recovery after fault is
eliminated
Power fault state output
The state switch is turned on when power is normal, otherwise off. state switch is
isolated with power
Ouput state indicate
Indicator lamps is on when ouput is normal
insulation
Insulation resistance
Input and shell: 500 VDC, >100 MΩ
Input and output: 500 VDC, >100 MΩ
Output and shell: 500 VDC, >100 MΩ
Dielectric Voltage withstan
Input and shell:1500 Vrms, 1 min., leakage current<10 mA
Input and output: 3000 Vrms, 1 min., leakage current <10 mA
Output and shell: 500 Vrms, 1 min., leakage current <20 mA
Environmental Condition
Ambient Temperature for
Operation
-10
℃
~+50
℃
, and full-load output in 50
℃
Storage Temperature
-20
℃
~+80
℃
RH
5%~95%, with no condensation
Physical Property
Module Dimension (W*H*D)
65.5 mm

125.2 mm

100 mm
Installation Pattern
Standard rail mounting
Standards and Certification
Safety certification
UL508,TUVEN60950, CE
EMC
EN55022/EN55011classB
EN61000-4-2/3/4/5/6/8/11
EN61000-3-2/3
EN61000-6-2
ENV50204
6.2 Extension Backboard
The extension backboard can only install IO module. E.g. LK117 for example, as shown in Figure 6-6,
Slot 1 is the communication module slot, installed with a LK-dedicated communication module. Slots
2~11 are I/O module slot, installed with an I/O module of the DP bus interface. Each terminal block
corresponds to an I/O module, directly connecting to the field signal via an I/O cable.
