HollySys LK Series User Manual

Chapter 7 IO Module
294 Beijing HollySys Intelligent Technologies Co., Ltd. All Rights Reserved
Parameter Name
Parameter Description
Value
CH1 Program Mode Output
CH1 Program Mode Output
Selection
0:Hold Last Value, output hold (default)
1: Program Mode Value, Output program mode
setting value
CH2 Program Mode Output
CH2 Program Mode Output
Selection
CH3 Program Mode Output
CH3 Program Mode Output
Selection
CH4 Program Mode Output
CH4 Program Mode Output
Selection
CH1 Program Mode Value
CH1 Programming Mode Set
Value
0 (default)~65535
See 7.9.4.1Data format for calculation method
CH2 Program Mode Value
CH2 Programming Mode Set
Value
CH3 Program Mode Value
CH3 Programming Mode Set
Value
CH4 Program Mode Value
CH4 Programming Mode Set
Value
CH1 Fault Mode Output
CH1 Fault Mode Output
Selection
0: Hold Last Value, output hold (default)
1: Fault Mode Value,output fault mode setting value
CH2 Fault Mode Output
CH2 Fault Mode Output
Selection
CH3 Fault Mode Output
CH3 Fault Mode Output
Selection
CH4 Fault Mode Output
CH4 Fault Mode Output
Selection
CH1 Fault Mode Value
CH1 Fault Mode Set Value
0(default)~65535
See 7.9.4.1Data format for calculation method
CH2 Fault Mode Value
CH2 Fault Mode Set Value
CH3 Fault Mode Value
CH3 Fault Mode Set Value
CH4 Fault Mode Value
CH4 Fault Mode Set Value
7.9.6 Technical Specifications
Table 7-72 Technical Specifications
LK510 4 Channel isolation voltage analog output module
Backplane power supply
Supply Voltage
24VDC(-15%~+20%)
Power consumption
125mA max. @ 24VDC
Output channel
Number of channels
4
Range code
18
17
16
Range
0~5.125V
0~10.25V
-10.25~0V
0~+10.25V
Output data format
0~ 65535
0~65535
32768~65535
0~32767
