HollySys LK Series User Manual

Chapter 7 IO Module
Beijing HollySys Intelligent Technologies Co., Ltd. All Rights Reserved 179
LK610 16-channel Leaking Type Digital Input Module
Rated Voltage of Field
Power Supply
24 VDC
Threshold Level
ON
10 VDC (2 mA) ~31.2 VDC (10 mA)
OFF
0~5 VDC (1.5 mA)
Dithering-removing Filter
Time
OFF→ON
ON→OFF
1 ms,3 ms, 5 ms, 10 ms, 15 ms, 20 ms, 25 ms, 30 ms optional for configuration
1 ms,3 ms, 5 ms, 10 ms, 15 ms, 20 ms, 25 ms, 30 ms optional for configuration
Reverse Protection
Max. reverse withstand voltage: 60 VDC.
Isolation Voltage
between Field and
System
500 VAC@1 min, leaking current: 5 mA
Failure Diagnosis and Hot Plug
Field Power Loss
Diagnosis
Bit2 in the diagnosis bytes (Bit0~Bit7) reported to the module is used to indicate the
information on field power supply detection. When Bit2=1 indicates field power loss, then
Bit2=0 indicates field power recovery. The field power failure diagnosis only reports once
separately when a failure occurs and the fault recovered.
Hot Plugging
Supported
Physical Property
Protection Key
D0
Installation Position
Extension backboard
Module Dimension
(W*H*D)
35 mm×100 mm×100 mm
Enclosure Protection
Rating
IEC60529 IP20
Weight
180g
7.2 LK710 16-channel Source Type Digital
Output Module
7.2.1 Basic Features
 16-channel MOSFET source type output
 Output voltage range: 10 VDC~31.2 VDC
 Output read-back diagnosis
 Field power loss detection
 Over Current Protection
 Fault mode output
 Isolation between the system and the field
 Programming mode output
 Hot swapping
