HollySys LK Series User Manual

Chapter 7 IO Module
Beijing HollySys Intelligent Technologies Co., Ltd. All Rights Reserved 243
LK430 6-channel Thermal Resistance Type Analog Input Module
Chinese_Cu: 50 Ω
-50
℃
~150
℃
0.6
℃
Nickel618: 100 Ω/120 Ω/200 Ω/500 Ω
-60
℃
~250
℃
0.9
℃
Nickel672: 120 Ω
-80
℃
~320
℃
1.4
℃
Platinum385: 100 Ω/200 Ω/500 Ω/1000 Ω
-200
℃
~870
℃
1.3
℃
Platinum3916: 100 Ω/200 Ω/500 Ω/1000
Ω
-200
℃
~630
℃
1.3
℃
Resistance Measurement
Range
1~4020 Ω
Resistance Measurement
Accuracy
0.1% F.S.@25
℃
Sampling Period
(Full-channel Scanning
Time)
The measured data is a
resistance value
The measured data is a
temperature value
Max.: 1.5 s
Max.: 2 s
Differential Mode Rejection
Ratio
60 dB
Common Mode Rejection
Ratio
100 dB
Temperature drift
±50 ppm/
℃
Calibration Accuracy
0.05% of resistance, full range
Calibration Period
12 months
Isolation Voltage between
Field and System
500 VAC@1 min, leaking current: 5 mA
Upload Data Format (0~65,535)
Uploaded Resistance for
Configuration Selection
65,535×(resistance value-Min. measurable resistance value in the range )/full
range resistance value
Uploaded Temperature for
Configuration Selection
Acquisition temperature ×10+10000
Failure Diagnosis and Hot Plug
Diagnosis
line broken detection
Over-limit alarm
When an line broken occurs, the diagnosis byte reports 0xA6, with the value
reported by the measured channel data optional for configuration
When the signal range exceeds Upper Limit Value/Lower Limit Value, the
diagnosis byte then reports 0xA7/0xA8
Hot Plugging
Supported
Physical Property
Protection Key
A2
Installation
Extension backboard
Module Dimension (W*H*D)
35 mm×100 mm×100 mm
Enclosure Protection Rating
IEC60529 IP20
Weight
180 g
