Chapter 4: Testing the Displays
MAN-09466 Revision 001 Page 13
4: Testing the Displays
This section provides detailed QC procedures for various displays. There are two
different QA software packages that can be used with Barco displays: QAWeb Enterprise
or MediCal QAWeb. The newer QAWeb Enterprise can be used with the displays
indicated in the following table.
Display
Barco Model
Number
Photometer
QC Software (QAWeb)
Enterprise
MediCal
Coronis Uniti MDMC-12133 Internal
 
High-Brightness MDMG-5221 Internal
 
Coronis MDCG-10130
MDMG-5121
MFGD-5621 HD
MFGD-5421
Internal
Internal
Internal
Internal
X
X
X
X




Nio MDNG-6121
MDNG-5121
MDNG-5221
External
External
Internal
X
X




4.1 Photometer Styles – Built-in vs. External
There are two types of display configurations:
• Built-in photometer sensor displays - Barco Uniti, High-Brightness, Coronis, and
Barco Nio MDNG-5221: The QAWeb software automatically runs the Hologic
Compliance Test and calibrates the Barco displays on a scheduled basis. The QAWeb
software relies on a built-in photometer sensor. No user intervention is required; you
only need to verify that the software ran the test as scheduled and that the results
were within the tolerance ranges. The default scheduled time is between 12:00
midnight and 2:00 AM.
• External photometer sensor displays - Barco Nio (MDNG-6121 and MDNG-5121):
The MediCal QAWeb software automatically alerts you to run the Hologic
Compliance Test and calibrate these Barco Nio displays on a scheduled basis. You
will use an external photometer to run the QC procedures. QAWeb Enterprise is not
supported for these displays.
Important
When testing the displays, ensure that the room lighting conditions are similar to those
used when reading studies.
