54
6. READOUT
SETTING
1. MAP
READOUT
Menu item Meaning of setting
2. OFF COURSE
ALARM
3. TEMP ALARM
4. FISH ALARM
5. DEPTH
ALARM
1. COASTLINE
2. COLOR OF SEA
3. DEPTH LINE
4. POINT NAME
5. NORTH/
COURSE UP
6. LAT/LON LINE
1. ALARM SET
2 COURSE WIDTH
SET
1 DEPTH LINE 1~3
4. SET LIST
5. DISPLAY RANGE
 is at factory setting.
Designate whether course off alarm function is used
or not. (page 47)
OFF: NOT USE ON: USE
Designate effective width of alarm.
(page 46) 0.50NM(km)
Alarm sounds within or out of two water temps.
(page 69)
Refer to fish finder function
(HE-6801 ,HE-6901only page 69)
Refer to fish finder function
(HE-6801 ,HE-6901only page 69)
Paint the land full to clarify boundary of land and
sea.
PAINTING ON: Paint full
OFF: Not paint full
LAND COLOR: Designate color of land which you
paint full.
COASTLINE COLOR: Designate coastline color
COLOR OF SEA Blue
Less than 1000m Dark Blue 1
more than 1000m Dark Blue 2
Select isobath you use and then set whether it is
indicated or not.
ON: Indicate OFF: Not indicate
Show isobath list
When range is enlarged than set range with [EXP]
key, etc., isobath is shown. 10
Designate whether POINT NAME W/ GREEN,
LIGHTHOUSE/BUOY 5, FISH HAVEN 1, COURSE
1, WRECK 1, RESTRICTED LINE or DANGEROUS
OBJECT 1 is indicated or not.
OFF: Not indicate
INPUT OF RANGE VALUE: Set with [CENTER] key
left/rightward. When range is enlarged than set,
each indication is shown.
NORTH UP: Just upper of display becomes
North.
COURSE UP: Just upper of display Bearing of
own boat.AUTO COURSE UP:Set whether
course-up is operated automatically or not.
(ON: Auto OFF: Manual) (page 21)
Designate whether grid (latitude/longitude line) is
indicated or not and its color. DARK GREEN
OFF: Not indicate ON: Indicate
COLOR: Select displayed color
