55
2. POSITION
DISPLAY
SETTING
3. OWN BOAT
READOUT
Menu item Meaning of setting
7. MAP SCROLL
8. TWIN MAP
1. LAT/LON
LORAN C
2. LORAN C SETUP
1. OWN BOAT
MARK
2.OWN BOAT
VECTOR
3. WAYPOINT
LINE
4. COURSE LINE
5.DISTANCE
MARKER
6. BOAT MARK
COLOR
7. W/LINE COLOR
8. COURSE LINE
COLOR
9. DIST MARKER
COLOR
1. CENTERING
2. MOVE DIRECTION
1. CHAIN
2.SLAVE STATION 1
3. SLAVE STATION 2
4. SLA STA1
CORRECT
5. SLA STA 2
CORRECT
is at factory setting.
ON: Scroll the map so that own boat’s position
keeps at center of screen when boat is sailing.
OFF: Displayed map does not scroll and own boat
moves when boat is sailing. When own boat moves
to edge of screen, map is replaced.
Set the direction of scroll when you scroll map with
[CENTER] key. NORMAL
Set single map display or dual map display.
OFF: Single map display
LEFT/RIGHT: Dual map display divided side by side
UPPER/LOWER: Dual map display upper and lower
Display method of own boat is set to LAT/ LON
or LORAN C TIME DIFFERENCE.
Set Loran C chain. (page 49 ) 8930
Set slave station of Loran C. (page 49 ) 30
Set slave station of Loran C. (page 49) 50
Set slave corrected value for slave station of Loran C.
(page 49 ) 0.00
Set slave corrected value for slave station of Loran C.
(page 49) 0.00
Designate type of own boats mark.
Designate whether own boats bearing is indicated
or not. (page 47)
OFF: Not indicate
SHORT: Indicate with short line
LONG: Indicate with long line
Straight line connected between own boat and
waypoint on route navigation is indicated or not.
OFF: Not indicate ON: Indicate
Straight line connected between own boat and
waypoint is indicated or not when waypoint
navigation is set.
OFF: Not indicate ON: Indicate
Certain radius of area (circle) is set as own boat is
center. Set with [CENTER] key left/rightwards.
Set area: 0 (Not indicated) 99NM 1.00NM(km)
However, set area (radius) is within Range/20.
Designate color of own boat mark.
Select with [CENTER] key left/right. WHITE
Designate color of waypoint line.
Select with [CENTER] key left/right. MAZENTA
Designate color of course line.
Select with [CENTER] key left/right. RED
Designate color of distance marker.
Select with [CENTER] key left/right. CYAN
