Honeywell Accenta Series - Alarm Test

Accenta/Optima Engineer’s Manual
19
1 = Alarm Test
This function tests the alarm function of the Bell, Strobe or Sounder. Pressing the appropriate button
[1-3] toggles the function ON or OFF. Using the [up arrow] also selects the appropriate alarm function.
Pressing the [0] button turns all alarm outputs to OFF.
Pressing the [SET] button toggles the selected alarm output.
Pressing the [RESET] button turns off all outputs and leaves the function.
The outputs are:
1 = Bell, 2 = Strobe, 3 = Sounder
NOTE: To test the Low volume sounder enable option 3 only. To test for a high volume sounder enable both
options 2 and 3 together.
LCD Keypad:
• Press [up arrow] for menu Alarm Test.
• Press [1] or [SET] to enter into first function ON or OFF.
• Press the [up arrow] or number [2] or [3] for the other functions.
• Press [RESET] to leave the menu.
LED keypad
The LED is lit when ON.
• Press [1] for menu Alarm Test.
• Press [1] or [SET] to toggle first function ON or OFF.
• Press number [2] and [3] for the other functions.
• Press [RESET] to leave the menu.
Alarm Test
[1]
[1] or [SET]
12
3
4
5
6
7
8
[RESET]
[2]
12
3
4
5
6
7
8
12
3
4
5
6
7
8
12
3
4
5
6
7
8
1>Alarm Test1>Alarm Test
1>Alarm Test1>Alarm Test
1>Alarm Test
[up arrow]
[1] or [SET]
01:Bell01:Bell
01:Bell01:Bell
01:Bell
OFFOFF
OFFOFF
OFF
[up arrow] or [Number]
02:Strobe02:Strobe
02:Strobe02:Strobe
02:Strobe
ONON
ONON
ON
[RESET]
1>Alarm Test1>Alarm Test
1>Alarm Test1>Alarm Test
1>Alarm Test
