Honeywell CNI2 User Manual

CNI2
O
perating and Installation
Guide
102
CALL PROGRESS AND ST
ATUS
Here is a typical sequence from the time the
CNI2
is powered
up to the time it completes its first
call. The
green
LED is mostly used to indicate the status of the radio and the network whereas
the
red
LED indicates the progress of the call.
After a reset all future calls start at Step
-
3.
1.
Upon power
-
up or reset
both LEDs
turn
on for 10
-
20 seconds:
2.
The
red
LED will turn off.
3.
The
green
LED will start flashing once per second.
4.
The radio is
powered up and initialized for communications. If this is successful the
green
LED’s flash rate will double.
5.
When
adequate
signal is detected and
the radio registers with the network the
green
LED’s flash rate will double again if the signal strength is less than 3 bars or will triple for
signal strength of 3 bars or more.
6.
The unit will start a call sequence
.
7.
While the
gree
n
LED continues to flash the
red
LED will begin flashing
once per second.
8.
When the unit has established a data connection to the network the
red
LED’s flash rate
will double.
9.
When the unit has gained access to the internet
(packet mode only)
the
red
LED’
s flash
rate will double again.
10.
When the unit establishes a connection with the data collection system (
DC
-
2009
®
or
MV90
®
)
both
LEDs will light solid
ly
at half intensity. The
red
LED’s intensity will increase
and decrease
(flicker)
during the time that t
he
CNI2
is communicating with
the host
.
11.
Once the call has completed both LEDs will return to flashing rapidly.
12.
The
red
LED’s flash rate will reduce as the data and network connections are
terminated.
13.
At the end of a successful call
both
LEDs will ligh
t solidly for 3 seconds.
If the call
was
unsuccessful
an error code will be displayed twice. A call will be attempted again
later
using the retry strategy defined by you
.
See the next section for a list of error codes.
14.
The
red
LED turns off.
15.
The
green
LED returns to the slowest flash rate as the radio is being powered down.
16.
Both LEDs are turned off when the unit enters its “sleep” mode.
LED STATUS INDICATOR
S
