perating and Installation
This terminal block is pre
wired to a high density reserve capacitor as illustrated below.
Normally this connection will not be altered, unless under special circumstances and
or Connection to TB1 (prewired)
efault function of J9 is to serve as a
trigger input. Activation of this inpu
the CNI2 to immediately call the central office.
Circuit connection is intended for a “dry” contact
h, meaning that it is a simple switch (or transistor) with no drive voltage. In most cases this
at the factory to a magnetic
This line can also be configured as
efault function of J11 is to serve as a power failure report input. This is useful for AC
mains applications where the loss of power can be reported to the
connection is intended for a “dry” contac
t switch, meaning that it is a simple switch (or transistor)
This line can also be configured as
efault function of J12 is to serve as
a tamper detect input. If
ordered then this alarm will trigger
time that the enclosure door has been opened.
CNI2 can be configured to place an immediate call to the central office when this occurs, or to
ent on the next scheduled call.
Circuit connection is intended for a “dry”
contact switch, meaning that it is a simple switch (or transistor) with no drive voltage.
