perating and Installation
Changing the Data Collection Configuration
On the next screen select the “Internet Ports” tab and select the “Add” button near the bott
the screen. A smaller selection window will appear. Place a checkmark in the “Enabled”
checkbox. Select “SIP Server” for the port type. The port number will be filled in automatically,
and must match the port number that was programmed into the CN
I2. The default is 50466. If
a different port number is being used then hold down the CTRL key on the keyboard, point to
the Port Number box and double click on the port number box. Then enter a new port number.
Enter the Internet address that was as
2009 and programmed into the CNI2. Your
computer systems’ administrator usually assigns this address.
2009 has a number of Inter
products. A maximum of 255
connections are allowed at the same time for all servers
. For instance if there are already 200
connections allocated for other products, you can only open another 55 connections for the SIP
server. If you have 50 devices in the field and only 10 connections allocated, then only 10
devices will be allowed to
connect at any one time. The devices can be scheduled to call in at
different times during the day to resolve this. The choice of how many to assign depends upon
the capabilities of the data collection computer.
