SETUP OPTIONS
5–21
5.6 RECORDING SCHEDULE, CONTINUED
Steps 9-15: Schedule camera 3 to record using MOTION.
When Motion occurs it will activate Relay Output #7 and #10.
9. Select Sch02 from the Schedule Number drop down list.
10. Select the Single Day Selection button, then select Yes.
11. Place a check in the boxes for SUN, MON, TUE, WED, THU, FRI, and SAT
days of the week.
12. On the Sch02 line (time selector grid), highlight the hours 00-23 and press Set.
13. Press Camera button #3 until the green Motion button is selected.
14. Press Relay buttons #7 and #10.
15. Press Apply to save.
