Custom map parameters
Revision 13 HC900 Process Controller Communications User Guide 93
April 2017
Table 6-30 Custom map AGA Gross parameters
Parameter Name
Access
Notes
Copy Entered Gas Vals Local
R/W
FLOAT 32 BIT
CO2 Entered
R/W
FLOAT 32 BIT
Hydrogen Entered
R/W
FLOAT 32 BIT
CO Entered
R/W
FLOAT 32 BIT
Method2 Nitrogen Entered
R/W
FLOAT 32 BIT
TB
R/W
FLOAT 32 BIT
PB
R/W
FLOAT 32 BIT
Use online Gas Analyzer Vals
R/W
FLOAT 32 BIT
Override Range Error
R/W
FLOAT 32 BIT
Method Used
R/W
FLOAT 32 BIT
Gas Rel Density
R/W
FLOAT 32 BIT
Rel Density Ref Temp
R/W
FLOAT 32 BIT
Rel Density Ref Press
R/W
FLOAT 32 BIT
Method1 Heat Val
R/W
FLOAT 32 BIT
Method1 Cal Ref Temp
R/W
FLOAT 32 BIT
Method1 Cal Ref Press
R/W
FLOAT 32 BIT
Method1 Comb Ref Temp
R/W
FLOAT 32 BIT
CO2 LCL
R
FLOAT 32 BIT
Hydrogen LCL
R
FLOAT 32 BIT
CO LCL
R
FLOAT 32 BIT
Method2 Nitrogen LCL
R
FLOAT 32 BIT
Table 6-31 Custom map AGA Detail parameters
Parameter Name
Access
Notes
Copy Entered Gas Vals Local
R/W
FLOAT 32 BIT
Methane Entered
R/W
FLOAT 32 BIT
Nitrogen Entered
R/W
FLOAT 32 BIT
CO2 Entered
R/W
FLOAT 32 BIT
Ethane Entered
R/W
FLOAT 32 BIT
Propane Entered
R/W
FLOAT 32 BIT
H2O Entered
R/W
FLOAT 32 BIT
H2S Entered
R/W
FLOAT 32 BIT
Hydrogen Entered
R/W
FLOAT 32 BIT
CO Entered
R/W
FLOAT 32 BIT
Oxygen Entered
R/W
FLOAT 32 BIT
I-Butane Entered
R/W
FLOAT 32 BIT
N-Butane Entered
R/W
FLOAT 32 BIT
I-Pentane Entered
R/W
FLOAT 32 BIT
N-Pentane Entered
R/W
FLOAT 32 BIT
Hexane Entered
R/W
FLOAT 32 BIT
Heptane Entered
R/W
FLOAT 32 BIT
Octane Entered
R/W
FLOAT 32 BIT
Nonane Entered
R/W
FLOAT 32 BIT
Decane Entered
R/W
FLOAT 32 BIT
Helium Entered
R/W
FLOAT 32 BIT
Argon Entered
R/W
FLOAT 32 BIT
TB
R/W
FLOAT 32 BIT
PB
R/W
FLOAT 32 BIT
