Honeywell HC900 - Table 6-10 SP Programmer Segments

Parameters accessible with Function Code 03, 06,10h
Set Point Programmer
62 HC900 Process Controller Communications User Guide Revision 13
April 2017
Set Point Profile Segments
The table below describes the registers that are part of a setpoint profile segment. A profile contains up to
50 segments and each segment consumes 8 registers, therefore each profile uses 400 contiguous registers.
To determine the actual register address for a parameter within a segment, add the register offset to the start
address of the segment. This table contains fixed addresses of SP Programmer #1 Segments; see Table 6-1
for starting addresses of other SP Programmer Segments.
The addresses given in Table 6-10 do not necessarily apply to segments in the custom map. For custom
addresses view or print a report in HC Designer.
Table 6-10 SP Programmer Segments
Fixed
Address
(Hex)
Fixed
Register
(Decimal)
Register
Offset
Parameter
Access
Notes
2800
10241
0
Segment #1 Ramp/Soak
Segment
Guaranteed Soak Enable
R/W
Bit Packed
Bit 0: 1 = ramp segment; 0=soak segment
Bit 1: 1 = guaranteed soak enabled
0 = guaranteed soak disabled
Bit 0 is ignored in the hold mode.
Writing to this register is not permissible in
the run mode.
2801
10242
1
Segment #1 Events
R/W
Bit Packed
Bit 0: Event #1
: :
Bit 15: Event #16
0: Event OFF 1: Event ON
Writing to this register is only permissible in
reset or ready mode.
2802
10243
2
Segment #1 Time or Rate
R/W
Floating Point in time units configured for the
set point programmer
Writing to this register is not permissible in
the run mode.
2804
10245
4
Segment #1 Ramp or Soak
value
R/W
Floating Point
Writing to this register is not permissible in
the run mode.
2806
10247
6
Segment #1 Soak value for
auxiliary output (use “Time
or Rate” for duration)
R/W
Floating Point
Writing to this register is not permissible in
the run mode.
2808
10249
8
Segment #2 Ramp/Soak
Segment
Guaranteed Soak Enable
R/W
Bit Packed
Bit 0: 1 = ramp segment; 0=soak segment
Bit 1: 1 = guaranteed soak enabled
0 = guaranteed soak disabled
Bit 0 is ignored in the hold mode.
Writing to this register is not permissible in
the run mode.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
298E
10639
398
Segment #50 Soak value
for auxiliary output (use
“Time or Rate” for
duration)
R/W
Floating Point
Writing to this register is not permissible in
the run mode.
